DO5 3 position solenoid operated directional control valve for directing fluid flow in hydraulic circuit. Featuring terminal box type electrical connection with indicator lights. Long life and quiet operation. P to T port / A and B port blocked in neutral position. All ports connected during spool shift.

Features

• Valve Size: D05
• Valve Type: Solenoid Control Valve
• Max Pressure: 3555 PSI
• Max Flow: 21.13 GPM

• Rated Flow: 13.25 GPM
• Spool Type: 4 Way/3 Position
• Neutral Position: P to T/A & B blocked
• Spool Action: Spring Centered
• Mounting Type: Manifold
• Electric Connection Type: Terminal Box
• Coil Voltage: 120 VAC
